IRangeX IRX4 LITE CC2500 NRF24L01+ A7105 CYRF6936 4 IN 1 Multiprotocol TX Module for Frsky X-Lite Jumper T Pro T Lite remote

Description

IRX4 LITE CC2500 NRF24L01+ A7105 CYRF6936 4 IN 1 Multiprotocol TX Module for Frsky X-lite Note:The STM32 MCU have change to ARM, fireware is ARM CORTEX-MThe new stock will be ARM, Existing inventory is not affectedSpecification:Brand name: IRangeXOperating voltage:5-9V                          Operating current: <=180mA    Operating frequency: 2.4G ISM band               RF power: +22dBm    MCU: ARM CORTEX-M(128K ROM, 20K RAM)    Weight: 32g   Overview:This 4-in-1 TX  module is suitable for FRSKY X-Lite. It integrates four RF chips (CC2500,NRF24L01+,A7105,CYRF6936) into one single circuit board, it supports a variety of remote control protocols, such as Futabas S-FHSS, Walkera DEVO, Spektrum DSM2, DSMX, Flysky, Frsky, WLToys, Hubsan, Hisky, Esky , Assan etc. You can control your model flexibility with it, and you will get much excellent experience with you favorite transmitter.This module is compatible with the Multi-module project on github. It’s based on ARM microcontroller. All available protocols are included in serial mode. In this mode, it uses a serial protocol to communicate with your transmitter. The serial protocol does not require any hardware modifications, but you should update the firmware on your transmitter to the latest. Then the model protocol selection and binding is done from the Model Settings menu on your transmitter. For telemetry capable transmitters, the telemetry integration is done seamlessly with the transmitter firmware.How to use:1. Refer to the website above, update your transmitter with proper firmware.2. Screw down the antenna of module tightly, and then install TX Module to the module bay of your transmitter.3. Power on your transmitter, enter Model Settings menu, turn on External RF , and select ‘MULT’ mode, then you will see the bind and protocol button in the menu, and then you can choose a proper protocol for you model and bind with it now. LED State:n n n Green Ledn Red Ledn Statusn n n OFFn Flashing raipidlyn Bootloader is running, please waitn n n ONn ONn Normal or Range Checkn n n ONn Flashing slowlyn No serial inputn n n ONn Flashing raipidlyn Bindingn n nn n Notice:n n 1. Make sure to check the ‘multimodule’ option, when you update OpenTX firmware through Companion software.n n 2. In serial mode, for FRSKY and S-FHSS protocol, you may need set the value of Fine or Option (in Model Settings menu on your TX) properly to bind with your model. The value can be varied, since it’s partly depended on your model.n n n Availableprotocols (incomplete andexpanding)n nn n n NO.n Protocoln Sub_protocoln RF Chipn n n 1n FLYSKYn FLYSKY  V9X9  V6X6   V912   CX20n A7105n n n 2n AFHDS2An PWM   PPM  IBUS  SBUSn A7105n n n 3n HUBSANn NONEn A7105n n n 4n FRSKYVn NONEn CC2500n n n 5n FRSKYDn NONEn CC2500n n n 6n FRSKYXn CH_8  CH_16  EU_8  EU_16n CC2500n n n 7n S-FHSSn NONEn CC2500n n n 8n DSMn DSM2_11  DSM2_22  DSMX_11  DSMX_22n CYRF6936n n n 9n DEVOn NONEn CYRF6936n n n 10n WK2X01n WK2801  WK2401n CYRF6936n n n 11n J6PROn NONEn CYRF6936n n n 12n ESKYn NONEn NRF24L01+n n n 13n HISKYn HISKY  HK310n NRF24L01+n n n 14n KNn WLTOYS  FEILUNn NRF24L01+n n n 15n V2X2n V2X2  JXD506n NRF24L01+n n n 16n ASSANn NONEn NRF24L01+n n n 17n MJXQn WLH08  X600  X800  H26D E010  H26WHn NRF24L01+n n n 18n YD717n YD717  SKYWLKR SYMAX4 XINXUN NIHUIn NRF24L01+n n n 19n SYMAXn SYMAX  SYMAX5Cn NRF24L01+n n n 20n SLTn SLT  VISTAn NRF24L01+n n n 21n CX10n GREEN _BLUE  DM007 JC3015  MK33041n NRF24L01+n n n 22n CG023n CG023  YD829  H8_3Dn NRF24L01+n n n 23n BAYANGn BAYANG  H8S3Dn NRF24L01+n n n 24n MT99XXn MT99  H7  YZ  LS  FY805n NRF24L01+n n n 25n SHENQIn NONEn NRF24L01+n n n 26n FY326n FY326  FY319n NRF24L01+n n n 27n FQ777n NONEn NRF24L01+n n n 28n HONTAIn HONTAI  JJRCX1  X5C1  FQ777_951n NRF24L01+n n n 29n Q2X2n Q222  Q242  Q282n NRF24L01+n n n 30n Q303n Q303  CX35  CX10D  CX10WDn NRF24L01+n n n 31n GW008n NONEn NRF24L01+n n n 32n DM002n NONEn NRF24L01+n n n 33n ESKY150n NONEn NRF24L01+n n n 34n CORONAn COR_V1  COR_V2  FD_V3n CC2500n n nn n Enable serial moden ,n Click heren n IRX4 lite module manualn ,n Click heren n n Package Included:n n 1 x IRX4 LITE TX Modulen n
